纸箱,纸板,包装试验机系列

XH-8001-D 纸箱抗压试验机

本机用于检测纸箱、容器等包装结构体之耐压强度,采用动态持压技术,模拟堆码试验,以了解产品包装物在运送、堆栈过程中之耐抗压能力。采用Load Cell感应,经计算机解析出抗压力数值并直接显示于荧幕上。 It`s used for measuring the resistance of cartons, containers, etc to compression. It uses the dynamic pressure-holding technology to simulate the stacking test so as to know the resistance of pacing materials to compression during transporting and stacking.It employs the Load cell asthe sensing device, and displays theresistance values directly via computer.

详细描述

主要规格参数


分解度 Resolution 1/200,000
精度 Accuracy±0.5% 以内 Within
容量选择 Capacity (optional) 20, 50, 100 kN
单位切换 Unit (switchable) Kgf,lbf,N,kN,kPa,Mpa
压缩空间 Test space (L×W×H)mm

1200x1200x1000

或指定or specified

压缩速度 Speed of compression0.001 200mm/min可调 adjustable
马达 MotorAC伺服马达 Servo motor

体积 Dimension

主机Main unit (DxWxH) cm

 160× 85× 160

电源Power
3∮, AC220V, 15A


产品规格如有变更,恕不另行告知,请以实际报价为准!
